Simpson Strong Tie THDB62500HMG 5/8" x 5" Titen HD Heavy Duty Screw Anchor Mechanically Galvanized - 10 per Box

• 5/8" x 5"

• Use with 5/8" Diameter Drill Bit

• Use with 15/16" Wrench or Socket

• 10 per Box

• Mechanical galvanizing meets ASTM B695, Class 65, Type 1

The Titen HD anchor is a patented, high-strength screw anchor for concrete and masonry. It is designed for optimum performance in both cracked and uncracked concrete; a requirement that the 2006 IBC places on post-installed anchors. The high strength, easy to install Titen HD anchor has been tested and shown to provide outstanding performance in cracked and uncracked concrete under both static and seismic loading conditions. The self undercutting, non-expansion characteristics of the Titen HD anchor make it ideal for structural applications, even at reduced edge distances and spacings. Recommended for permanent dry, interior non-corrosive environments or temporary outdoor applications. Mechanical galvanizing meets ASTM B695, Class 65, Type 1. Intended for some pressure-treated wood sill plate applications. Not for use in other corrosive or outdoor environments.
