Simpson Strong Tie HGUS5.50/12 5-1/2" x 12" Heavy Double Shear Girder SCL Hanger

• 12 Gauge
• 5-1/2"W x 10-1/2"H x 4"B
• Use with 16d Fasteners
• Zinc galvanized finish containing 0.90oz of zinc per square foot of surface area (total both sides)

All hangers in this series have double-shear nailing. This patented innovation distributes the load through two points on each joist nail for greater strength. It also allows the use of fewer nails, faster installation, and the use of common nails for all connections. (Do not bend or remove tabs)
